Data sheet

gear ratio

150.58:1

torque (stall)

33 oz-in (2.4 kg-cm)

voltage

6 V

shaft diameter

3 mm (D shaped)

stall current

1.6 A (@ 6V)

current

70 mA (@ 6V, no load)

dimensions

26mm x 10mm x 12mm

shaft length

9.3 mm

rpm

210 rpm (@ 6V, no load)
